CSP-3508F 8 Ports IP Input IP Output IPTV Gateway

Available: In Stock
$0.00
Compare
  • Order within

CSP-3508F IPTV Gateway is a device which is used for the protocol conversion scenariosand streaming media distribution scenarios. It can convert the broadcast network IP stream over HTTP,UDP, RTP,RTSP and HLS and Ts file into HTTP, UDP, HLS and RTMP protocol. The system can achieve the integration by receiving a variety of commercial streaming media services.Also, the system can provide streaming media services directly.

CSP-3508F IPTV Gateway is a device which is used for the protocol conversion scenariosand streaming media distribution scenarios. It can convert the broadcast network IP stream over HTTP,UDP, RTP,RTSP and HLS and Ts file into HTTP, UDP, HLS and RTMP protocol. The system can achieve the integration by receiving a variety of commercial streaming media services.Also, the system can provide streaming media services directly.

Input IP input thru CH 1-7(1000M) over HTTP, UDP(SPTS), RTP(SPTS), RTSP (over
UDP, payload: mpeg TS) and HLS TS files uploading through Web management
IP output



IP out thru Data port (1000M) over HTTP (Unicast), UDP(SPTS, Multicast) HLS
and RTMP (Program source should be H.264 and AAC encoding)
IP out thru CH 1-7(1000M) over HTTP, HLS and RTMP (Unicast)






System
Memory: 4G
Solid-State Disk(SSD): 16G
Channel switching time with CATVSCOPE’ STB: HTTP (1-3s), HLS (0.4-0.7s)
Support adding scrolling caption, welcome words, boot image and boot video
(this function is only applicable to IP out application and the STB/Android TV
must be installed CATVSCOPE IPTV APK)
Play programs with APK downloaded android STB and TV, maximum 150 terminals
Support about 80 HD/SD programs (Bitrate: 2Mbps)
When HTTP/RTP/RTSP/HLS is converted into UDP (Multicast), the actual application shall prevail, and suggest maximum 80% CPU utilization
web-based NMS management thru DATA port


General
Size 482mm×324mm×44mm (WxLxH)
Temperature 0~45℃(operation), -20~80℃(storage)
Power Supply AC 100V±10%, 50/60Hz or AC 220V±10%, 50/60Hz
