CSP-3306I 6 Ways IP to ISDB-T Modulator IP Input RF Output

Available: In Stock
$2,635.00
Compare
  • Order within

CSP-3306I 6 in 1 ISDB-T modulator is the latest generational Mux-modulating device developed by CATVSCOPE. It has 6 multiplexing channels and 6 (ISDB-T) modulating channels, and supports maximum 192 IP input through the 3 GE ports and 6 non-adjacent carriers (50MHz~960MHz) output through the RF output interface. The device is also characterized with high integrated level, high performance and low cost. This is very adaptable to newly generation DTV broadcasting system.

CSP-3306I 6 in 1 ISDB-T modulator is the latest generational Mux-modulating device developed by CATVSCOPE. It has 6 multiplexing channels and 6 (ISDB-T) modulating channels, and supports maximum 192 IP input through the 3 GE ports and 6 non-adjacent carriers (50MHz~960MHz) output through the RF output interface. The device is also characterized with high integrated level, high performance and low cost. This is very adaptable to newly generation DTV broadcasting system.


Input
Input Max 192 IP input through 3 (front-panel Data port, Data 1 and Data 2) 100/1000M Ethernet Port (SFP interface optional). Each Data1 or Data 2 port can input max 192 IP, while front-panel Data port can input max 128 IP
Transport Protocol TS over UDP/RTP, unicast and multicast, IGMP V2/V3
Transmission Rate Max 840Mbps for each GE input


Mux
Input Channel 192
Output Channel 6
Max PIDs 180 per channe
Functions
PID remapping (auto/manually optional) PCR accurate adjusting
PSI/SI table automatically generating




Modulation
Parameters
Standard ARIB STD-B31
Bandwidth 6M
Constellation QPSK, 16QAM, 64QAM
Guard Interval 5.0~7.0Msps, 1ksps stepping
Constellation 1/32, 1/16, 1/8, 1/4
Code rate 1/2, 2/3, 3/4, 5/6, 7/8




RF Output
MER ≥40dB
RF Range 50~960MHz, 1kHz stepping
Output Level -20dBm~+10dBm(87~117dbµV), 0.1dB stepping
Interface 1 F typed output port for 6 carriers, 75Ω
impedance
ACLR -50 dBc
TS output 6 IP output over UDP/RTP/RTSP, unicast/multicast, 2 (Data1& Data2)
100/1000M Ethernet Ports
System Network management software (NMS) supporting



General
Dimensions 420mm×440mm×44.5mm (WxLxH)
Weight 3kg
Temperature 0~45℃(operation), -20~80℃(storage)
Power Supply AC 100V±10%, 50/60Hz or AC 220V±10%, 50/60Hz
Consumption 15.4W
